Class II Biosafety Cabinet Type B2 Manufacturers in India
Aeromech manufactures and supplies Class II Biosafety Cabinet Type B2 systems designed for personnel, product and environmental protection during biological and chemical handling. The cabinet uses vertical HEPA-filtered airflow with 100% external exhaust through a dedicated hard-duct system.
Aeromech supplies Class II Biosafety Cabinet Type B2 systems across Chennai, Coimbatore, Bengaluru, Hyderabad, Kochi, Pune, Mumbai, Ahmedabad, Indore, Bhubaneswar, Kolkata, New Delhi, Gurugram and Mohali.
- ISO Class 5 Work Area
- 100% External Exhaust
- Product, Personnel & Environment Protection
Cleanroom Systems Installed
Support Across Major Indian Cities
Configuration Based on Your Requirement
Testing, Maintenance and Service Assistance
What Is Class II Biosafety Cabinet Type B2?
A Class II Biosafety Cabinet Type B2 is a ventilated containment cabinet designed to protect the operator, the product and the surrounding environment. Unlike recirculating Type A2 cabinets, a Type B2 cabinet exhausts 100% of the air drawn through the cabinet to the outside through a dedicated duct system.
HEPA-filtered vertical downflow protects the work area, while inward airflow through the front opening helps protect the operator. Air leaving the cabinet passes through HEPA filtration before being discharged through the external exhaust system.
How Class II Biosafety Cabinet Type B2 Works?
- Room air enters through the front opening.
- Inward airflow helps protect the operator.
- HEPA-filtered air flows vertically over the work area.
- Air is collected through the cabinet grilles.
- No cabinet air is recirculated.
- 100% of the air passes through the exhaust system.
- Filtered exhaust air is discharged externally through a hard duct.
Class II Biosafety Cabinet Type B2 Applications
Aeromech Class II Biosafety Cabinet Type B2 systems are suitable for:
- Pharmaceutical laboratories
- Biotechnology laboratories
- Clinical laboratories
- Research institutions
- Chemical-processing laboratories
- Microbiology laboratories
- Diagnostic laboratories
- Biological research
- Applications involving limited chemical vapours with biological work
- Containment applications requiring 100% external exhaust
The material, process and associated hazards must be reviewed before selecting an Class II Biosafety Cabinet Type B2 cabinet.
Important Product-Selection Notice
Class II Biosafety Cabinet Type B2 is designed for applications that require personnel, product and environmental protection together with complete external exhaust of cabinet air.
Selection should consider:
- Biological agents being handled
- Chemical vapours used during the process
- Required cabinet size
- Front-opening dimensions
- Inflow and downflow requirements
- Hard-duct exhaust arrangement
- Building exhaust capacity
- Laboratory ventilation
- HEPA filtration
- Testing and certification requirements
- Utility requirements
- Maintenance access
A Type B2 cabinet requires a dedicated external exhaust system and should be coordinated with the laboratory HVAC and exhaust design.
Class II Biosafety Cabinet Type B2 Features
All air handled within the cabinet is exhausted externally. No contaminated cabinet air is recirculated back into the work area.
Controlled inflow, HEPA-filtered downflow and filtered external exhaust work together to protect the operator, samples and surrounding laboratory environment.
The cabinet working zone is designed for ISO Class 5 cleanliness as per ISO 14644-1.
The cabinet maintains a minimum inflow velocity of 0.45 m/s at the specified front opening and a downflow velocity of 0.30 m/s.
Type B2 cabinets require hard-duct connection to an external exhaust system for continuous removal of cabinet air.
The microprocessor control provides airflow display, UV interlocking, low-airflow alarm and supply and exhaust filter-failure indication. Aeromech
Class II Biosafety Cabinet Type B2 Specifications & Options
| Specification | Standard Product Information |
|---|---|
| Product | Class II Biosafety Cabinet Type B2 |
| Type | Tabletop / Stand Mounted |
| Airflow Pattern | Vertical |
| Air Balancing | 0% Recirculation / 100% Exhaust |
| Protection | Product, Personnel & Environmental Protection |
| Exhaust Duct Requirement | Hard Duct Only |
| Control Plenum | Surrounded by Negative Plenum |
| Cleanliness Level | ISO Class 5 as per ISO 14644-1 |
| Inflow Velocity | Minimum 0.45 m/s (90 FPM) at 8-inch Front Opening |
| Downflow Velocity | 0.30 m/s (65 FPM) |
| Main Body MOC | Galvanized Iron with PU Coating / Stainless Steel with Satin Finish |
| Working Area MOC | Stainless Steel IS 304 Grade, Satin Finish |
| Supply Filter | HEPA Filter H14 Grade |
| Supply Filter Efficiency | 99.99% down to 0.3 Microns |
| Exhaust Filter | HEPA Filter H14 Grade |
| Exhaust Filter Efficiency | 99.99% down to 0.3 Microns |
| Pre-Filter | Aeromech Make, EU4 Rating |
| Pre-Filter Efficiency | 90% down to 10 Microns |
| Noise Level | Less than 70 dB(A) |
| Light Intensity | Minimum 900 Lux inside Working Area at Ambient Zero |
| Vibration Level | Minimum |
| Differential Pressure Gauge | Magnehelic Gauge, Dwyer USA |
| Motor Blower Assembly | Induction Motor with Centrifugal Blower |
| Blower Balancing | Statically and Dynamically Balanced |
| Blower Mounting | Spring Suspension System |
| Electrical Socket | 15 AMP, 3-Pin Switch & Socket |
| Controls | ON/OFF Switches for Motor Blower and Lights |
| Microprocessor Control | Airflow Display, UV Interlocking, Low Airflow Alarm, Supply & Exhaust Filter Fail Indication |
Standard components
Depending on the approved model, the standard configuration includes components specified for the Class II Biosafety Cabinet Type B2 system such as:
- Germicidal UV lamp
- Cool white LED light
- Magnehelic gauge
- UV-stabilised polycarbonate front door
- Nylon castor wheels
- Levelling leg
- Combined socket switch
Is Class II Biosafety Cabinet Type B2 Right for Your Application?
Class II Biosafety Cabinet Type B2 is suitable where biological work requires product, personnel and environmental protection together with complete external exhaust of cabinet air.
It can be considered for:
- Biological procedures involving chemical vapours
- Pharmaceutical research
- Biotechnology research
- Clinical laboratory work
- Microbiological procedures
- Diagnostic applications
- Research involving biological materials
- Processes requiring non-recirculating cabinet airflow
Class II Biosafety Cabinet Type B2 Manufacturers in India
Aeromech manufactures Class II Biosafety Cabinet Type B2 systems for pharmaceutical companies, biotechnology facilities, clinical laboratories, research institutions and controlled laboratory environments.
The cabinet can be configured according to:
- Required cabinet size
- Tabletop or stand-mounted installation
- Main body construction
- Working-area dimensions
- Hard-duct exhaust configuration
- Laboratory layout
- Required accessories
- Exhaust blower arrangement
- Testing and certification scope
The Type B2 design provides 100% external exhaust, making it suitable for processes where cabinet air must not be recirculated.
Class II Biosafety Cabinet Type B2 Suppliers in India
Aeromech supplies Class II Biosafety Cabinet Type B2 cabinets to customers across major Indian industrial and research locations. Our supply process can include:
We review the application, material type, required work area, project location and preferred configuration.
Aeromech recommends a suitable product configuration based on the information provided.
The selected dimensions, materials, components, options and documentation are confirmed before manufacturing.
The cabinet is manufactured and inspected according to the approved product scope.
The product is delivered to the agreed location. Installation and commissioning services can be included where applicable.
Applicable testing, documentation and operator guidance can be provided according to the order scope.
Class II Biosafety Cabinet Type B2 Price
Class II Biosafety Cabinet Type B2 price depends on the cabinet size, construction material, filtration arrangement, exhaust system, hard ducting, controls, accessories and testing requirements.
- Cabinet width and work-area size
- Tabletop or stand-mounted configuration
- Galvanized Iron or stainless steel construction
- Supply HEPA filter size
- Exhaust HEPA filter size
- Hard-duct exhaust arrangement
- Exhaust blower requirement
- Microprocessor controls
- Front-door configuration
- UV lamp
- LED lighting
- Pressure monitoring
- Optional accessories
- Installation scope
- Testing and certification
- Quantity
- Project location
Frequently Asked Questions
Find answers to the most common questions about Class II Biosafety Cabinet Type B2
What is a Class II Biosafety Cabinet Type B2?
A Class II Biosafety Cabinet Type B2 is a ventilated containment cabinet that provides protection for personnel, products and the environment using controlled inflow, HEPA-filtered vertical downflow and 100% external exhaust.
What is the airflow balance in a Type B2 Biosafety Cabinet?
A Type B2 cabinet uses 0% recirculated air and 100% exhaust air. All cabinet air is discharged externally through the exhaust system.
What is the inflow velocity?
The specified minimum inflow velocity is 0.45 m/s, or 90 FPM, at an 8-inch front opening.
What is the downflow velocity?
The specified downflow velocity is 0.30 m/s, or 65 FPM.
What cleanliness level does the cabinet provide?
The working area is designed for ISO Class 5 cleanliness as per ISO 14644-1.
What HEPA filter efficiency is specified?
The supply and exhaust HEPA filters are specified at 99.99% efficiency down to 0.3 microns.
Does a Type B2 Biosafety Cabinet require ducting?
Yes. Aeromech Class II Biosafety Cabinet Type B2 requires a hard-duct connection for 100% external exhaust.
What is the difference between Type A2 and Type B2 Biosafety Cabinets?
A Type A2 cabinet recirculates a portion of its HEPA-filtered air and exhausts the remainder. A Type B2 cabinet does not recirculate cabinet air and exhausts 100% of the air through a dedicated external duct.
Does Aeromech manufacture Class II Biosafety Cabinet Type B2?
Yes. Aeromech manufactures Class II Biosafety Cabinet Type B2 with configurations based on the application, required dimensions, construction material and technical requirements. Contact our team to discuss available options.
What is the price of Class II Biosafety Cabinet Type B2?
The price of Class II Biosafety Cabinet Type B2 depends on the size, construction material, technical specifications, optional features, quantity and delivery location. Share your requirements with Aeromech for a customised quotation.
What services does Aeromech offer for Class II Biosafety Cabinet Type B2?
Aeromech offers product-selection assistance and applicable installation, testing, maintenance and after-sales support for Class II Biosafety Cabinet Type B2. The available services depend on the product configuration, project location and agreed scope.
Does Aeromech supply Class II Biosafety Cabinet Type B2 across India?
Yes. Aeromech supplies Class II Biosafety Cabinet Type B2 across major cities and industrial areas in India including Chennai, Coimbatore, Bengaluru, Hyderabad, Kochi, Pune, Mumbai, Ahmedabad, Indore, Bhubaneswar, Kolkata, New Delhi, Gurugram, Mohali.
Delivery schedules, freight and installation arrangements depend on the selected configuration, quantity and project location.
Why choose Aeromech?
Aeromech reviews the intended process before recommending a product configuration.
Cabinet dimensions, construction materials, side panels, monitoring and accessories can be selected according to the approved requirement.
Applicable specifications and drawings are documented before manufacturing.
Aeromech supplies cleanroom and laboratory equipment across major Indian locations.
Installation, commissioning and applicable performance testing can be included in the project scope.
Maintenance, filter replacement, performance testing and other applicable support are available after installation.
